Professional LCD Manufacturer Make LCD Simple
10 Years
| Ask Lasest Price | |
| Brand Name : | INNOLUX |
| Model Number : | AT070TN83V.1 |
| Price : | Negotiable |
| Supply Ability : | 2000pcs per month |
| Delivery Time : | 25~30days |
| Certification : | ROHS |
Original INNOLUX AT070TN83V.1 800*480 7inches TFT LCD Panel
PRODUCT DESCRIPITION
AT080TN64 supports display 800(RGB)×480 (WVGA) with aspect ratio of
16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As
for mechanical detail, it features active area of
176.64(W)×99.36(H) mm, outline size of 192.8(W)×116.9(H)×6.7(D) mm,
viewing area size of 180.1(W)×103.4(H) mm, with surface treament of
Antiglare, net weight of 245g (Typ.).
| Panel Brand | INNOLUX |
| Model Number | AT070TN83V.1 |
| Driver element | a-Si TFT-LCD , Panel |
| Panel Size | 7.0 inch |
| Resolution | 800*480 |
| Display Mode | Normally White, Transmissive |
| Surface Treatment | Antiglare |
| Dot pitch | 0.0635(W)X0.1905(H) mm |
| Active area | 152.4 (W)X91.44 (H) mm |
| Module size | 165(W)X104(H)X5.5(D) mm |
| Color arrangement | RGB-stripe |
| Interface | Digital (TTL) |
| Backlight power consumption | 2.500W (Typ.) |
| Panel power consumption | 0.825W (Typ.) |
| Weight | 130g |
OUR SERVICE ADVANTAGES
• Long lasting product cycle for continuity thru all phases of project rollouts and servicing
• Competitive price for different brands hard disk.
• Mass stock with the better price.
• Multiple options.
• Warranty service.
• Better team to provide the before-sales, on-sale and after-sale service
• Pls send us message if any hard disk needed.
|
|
