Professional LCD Manufacturer Make LCD Simple
10 Years
| Ask Lasest Price | |
| Brand Name : | ROYAL DISPLAY |
| Model Number : | RYTC55215Q-01 |
| Certification : | RoHS |
| Price : | Negotiable |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 300,000 Piece/Pieces per Year |
| Delivery Time : | 7~10 working days |
5.5'' 1080X (RGB) X1920 Android TFT LCD Display Module
PRODUCT DESCRIPTION
| Item | Description |
| Model Name | RYTC55215Q-01 |
| Product type | TFT LCD Module |
| Screen Size | 5.5" |
| Resolution | 1080X3(RGB)X1920 |
| Module Size(mm) | 70.64 X129.21X 1.47 |
| Active Area(mm) | 101.57X76.18 |
| Viewing Angle (Tpy.)θT/θB/θL/θR | ALL |
| Backlight | 14 Chip-white |
| Polarizer Mode | Transimissive Positive |
| LCD Driver | HX8399C |
| Operation Temperature( ºC) | -20º C~70ºC |
| Storage Temperature (ºC) | -30º C~80ºC |
PRODUCTS QUALITY ASSURANCE
1. High-quality raw material supplier
after-sales guarantee and long-term stable supplier, LCD panel and
Driver IC made of A-regulated raw materials.
2. Other materials
such as polarizers, backlight film materials, etc. We also use
brand new A-regulated raw materials
3. Strict quality control
Through rate up to 98.5%,Customer online defect rate as low as
0.3%.
Inspection is done in FOG==>LCM==>LCM+RTP/CTP==>
production online inspection ==>Q.C inspection==>aging test 4
hours with load in 60 ℃ special room (as option)==>OQC.
A product must pass 5 tests before shipment: incoming inspection,
100% online inspection, QC on-site inspection, aging test and OQC
inspection, etc.
OUR SERVICE ADVANTAGES
1) CUSTOMER FOCUSED
We’re here to serve customers, and they receive our unwavering
focus. We also continually communicate with those we serve,
encouraging feedback on how we can better meet their needs and
expectations. This helps guide our priorities and methodology.
2) EFFECTIVE TEAMWORK
We feel a team-based approach works best, for all engagements.
Effective teamwork demands strong relationships, respect, and
diversity of thought from all contributors, and we foster an
environment where those are stimulated.
3) ADVANCED FACILITIES
The advanced facilities and automated production lines in
designated class 100 and class 1000 clean rooms ensure the product
quality.
With the pioneering technical team and sophisticated manufacturing
facilities, Royal’s products and services are both competitive and
quality.
4) INTEGRATED SOLUTIONS
We propose most suitable display solutions to our customers
integrated with capacitive touch functions and optical bonding
solutions.
The wide selection and integrated solutions of display technologies
in our company meet the customers' effective one-stop customization
requirements. This includes LCM, TFT, OLED, EPD, CTP and optical
bonding.
ACCESSORIES
Royal Display can provide many accessories to go with your display.
If you would like to source a connector, cable, test jig or other
accessory preassembled to your LCD (or just included in the
package), our team will make sure you get the items you need. Get
in touch with a team member today to accessorize your display!
WARRANTY
Royal Display offers the original purchaser who has purchased a
product from the lcdmoduletft.com a limited warranty that the
product (including accessories in the product's package) will be
free from defects in material or workmanship.
ABOUT US
Royal Display Co., Ltd has been specializing in LCD business for
more than 10 years, products range LCD Display, LCD Screen, LCD
Module, Character LCD, LED backlight display, TFT display, Graphic
LCD, 7 segment LED Display.
More than 90% of our products is specially customer designed to be
used in Video and Audio system, financial, medical, industry
equipment, testing devices, Electronic meters, facsimiles, many
kinds of terminal equipment and so on. With the capability of 300K
different kinds of LCM/LCD per month.
FAQ
1. What is the MOQ?
Re: No MOQ for samples,different MOQ requirements for bulk order.
2. What about the delivery time?
Re: For standard product,1 week for samples,4 weeks for bulk order;
For customization,3-4 weeks for samples,4 weeks for mass production
after sample confirmation.
3. Is there any warranty for your products?
Re: Yes,we offer 12-month warranty for unartificial defect.
4. What is your payment method?
Re: We support make payment via TT/West Union/Paypal,50%-100%
deposit in advance and balance before shipping as order amount.
|
|
