Professional LCD Manufacturer Make LCD Simple
10 Years
| Ask Lasest Price | |
| Brand Name : | ROYAL DISPLAY |
| Model Number : | RYP1602A-8 |
| Certification : | SGS ROHS |
| Supply Ability : | 500k/Month |
| Delivery Time : | 25~28 Working Days |
| Price : | Negotiable |
STN Yellow Green Display 1602 Character LCD with Y-G Backlight
| Item | Description |
| Product Name | 16x2 COB LCD Module |
| Model No. | RYP1602A-8 |
| Dot Format | 16 x 2 |
| Outline Dimension(mm) | 80.0 x 36.0MAX |
| Assem. Size(mm) | 75.0 x 31.0 |
| Viewing Area(mm) | 64.6 x 16.0 |
| Character Size( mm) | 2.95 x 5.55 |
| Viewing Angle | 6 O' clock |
| LCD Type | STN-YG |
| Backlight | Yellow Green |
| Driver IC | AIP31066 |
| Power supply | 3.3V or 5V |
| Interface | Parallel |
| Operating Temp | -20º C~70º C |
| Storage Temp | -30º C~80º C |
Typical Applications:
Car Radios , Industrial Instruments,meter for measuring electricity , Clusters, Air conditioner, Price Tag, Printer, Fax, etc
Features:
Wide Operation & Storage temperature range
(Top:-30~+85℃； Tst:-40~+90℃)
Small color change vs. Temperature
Suitable for all kinds of backlight (white/red/blue etc.)
Transmissive negative Mode
Duty Ratio: 1: 1 to 1: 33 (MP)
Super black background
Super high contrast ratio(up to 1000:1)
|
|
