Professional LCD Manufacturer Make LCD Simple
10 Years
| Ask Lasest Price | |
| Brand Name : | ROYAL DISPLAY |
| Model Number : | RYTW70NP03-16-2 |
| Certification : | SGS, ROHS |
| Price : | Negotiable |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 300k/Month |
| Delivery Time : | 15~25 working day |
All View 1024rgbx600 Color Screen 7'' TFT LCD Display with CTP Touch Panel
Product Description
The 7-inch color screen is a larger size LCD with a larger display area and higher resolution. It uses TFT (Thin Film Transistor) liquid crystal technology, which has a high refresh rate and color performance capabilities. The brightness of a 7-inch LCD screen can reach over 1000cd/m ^ 2, while the indoor environment brightness is only 50-100cd/m ^ 2. Therefore, the 7-inch LCD screen has very high brightness and is not affected by external light. Its high color is a key feature of color display, which can meet the diverse requirements of the human eye for color, making the image appear clearer and more lively.
The datasheet of RYTW70NP03-16-2 7'' TFT LCD
| Item | STANDARD Value |
| LCD size | 7 inch(Diagonal) |
| Driver element | a-Si TFT active matrix |
| Resolution | 1024RGB(H)x600(V) |
| Display mode | Normally white, Transmissive |
| Outline Dimension | 164.9(W) x 100(H) x7.5 (D)mm |
| Active area | 154.21(H) x 85.92(V) mm |
| Pixel Arrangement | RGB-Vertical Stripe |
| Surface treatment | Anti-Glare |
| Display Mode | Normally Black/Transmissive |
| TP | 8WIRE -CTP |
| Gray scale inversion Direction | All |
| Viewing Direction | All |
| Top & Tst | -20˚C ~ +70˚C &-30˚C-~+80˚C |
The Drawing of RYTW70NP03-16-2 7'' TFT LCD
Product Features
Compared with LCD screens of other sizes, the 7-inch TFT LCD screen has some unique features:
1. Compact size: It is a moderate display screen suitable for mobile devices and some portable electronic products.
2. High resolution: It usually has a higher resolution and can present clear and detailed images and text.
3. High contrast: It generally provide high contrast.
4.Vibrant Colors: It generally delivers vibrant colors.
5. Fast response: It usually have fast response speed, that is, the speed at which the image refreshes.
Product Applications
The 7-inch color screen is a large-size LCD display with a larger
display area and higher resolution, and is suitable for a variety
of application scenarios.
1. Tablets and mobile devices: 7-inch color screens are commonly
used on tablets and other mobile devices, providing a larger
display area and better visibility.
2. Car navigation and entertainment systems: They can be used to
display navigation maps, vehicle information, music playback
interfaces, rear-view cameras, etc., providing rich navigation and
entertainment functions.
3. Industrial control and monitoring systems: The 7-inch color
screen is suitable for industrial control and monitoring systems
and is used to display equipment status, process parameters, data
charts and operating interfaces, etc.
4. Medical equipment and instruments: 7-inch color screens are
widely used in medical equipment and instruments, such as medical
monitors, ultrasound diagnostic equipment, surgical navigation
systems, etc.
5. Hotel and commercial display screens: 7-inch color screens can be used for information displays in hotels and commercial places to display advertisements, guides, event information, menus and other content.
Special Customized
We provide the following customized services
1. Customization of different sizes
2. Customization from different perspectives
3. Customization with different resolutions
4. Is it equipped with a touch screen
5. Type of touch screen
6. Customization Display Mode
7. Other speicial Customization
FAQ
1. Do you offer customized service?
-Yes, we offer OEM&ODM service and send us your requirements.
2. What payment methods do you accept?
-We accept via TT/West Union/Paypal.
3.Do you provide samples?
-Yes, we offer sample but you need to pay sample fee and delivery
fee.
4. How long does it take to produce the product?
-It depends on the product you need. Usually 15~30 working days.
5. What's the process for placing an order?
-PO is placed by clients → PI is issued by Royal Display → Payment
by clients → Lead time is confirmed by Royal Display → Shipping
instruction by Clients → Delivery → Cargo tracking → Receipt of
cargo
|
|
